Light your Home with the Best LED Downlight with Gran Lightings


LED Down Light

Edge lit
Grand

LED Downlight


Item Code Power Col.Temp PF Light Flux Dimension Cut. Dia. CRI Angle
OS-T01-3R 6 3000K >0.6 450-480lm 110*47.5 75 80 120
OS-T01-3R 6 4000K >0.6 450-480lm 110*47.5 75 80 120
OS-T01-3R 6 6500K >0.6 450-480lm 110*47.5 75 80 120
OS-T01-3R 6 3IN1 >0.6 450-480lm 110*47.5 75 80 120
OS-T01-3R 6 RED >0.6 110*47.5 75 80 120
OS-T01-3R 6 BLUE >0.6 110*47.5 75 80 120
OS-T01-3R 6 PINK >0.6 110*47.5 75 80 120
OS-T01-3R 6 GREEN >0.6 110*47.5 75 80 120
Grand

LED Downlight


Item Code Power Col.Temp PF Light Flux Dimension Cut. Dia. CRI Angle
OS-T03-3R 6 3000K >0.6 450-480lm 110*43.5 75 80 120
OS-T03-3R 6 4000K >0.6 450-480lm 110*43.5 75 80 120
OS-T03-3R 6 6500K >0.6 450-480lm 110*43.5 75 80 120
OS-T03-3R 6 3IN1 >0.6 450-480lm 110*43.5 75 80 120
OS-T03-3R 6 RED >0.6 110*43.5 75 80 120
OS-T03-3R 6 BLUE >0.6 110*43.5 75 80 120
OS-T03-3R 6 PINK >0.6 110*43.5 75 80 120
OS-T03-3R 6 GREEN >0.6 110*43.5 75 80 120
Grand

LED Anti-Glare Downlight


Item Code Power Col.Temp PF Light Flux Dimension Cut. Dia. CRI Angle
OS-T05-4R 12 3000K >0.9 1080-1200lm 120*50 115 80 120
OS-T05-4R 12 4000K >0.9 1080-1200lm 120*50 115 80 120
OS-T05-4R 12 6500K >0.9 1080-1200lm 120*50 115 80 120
Grand

LED Downlight


Item Code Power Col.Temp PF Light Flux Dimension Cut. Dia. CRI Angle
OS-T13-3R 7 3000K >0.5 210-350lm 80*50 75 80 60
OS-T13-3R 7 4000K >0.5 210-350lm 80*50 75 80 60
OS-T13-3R 7 6500K >0.5 210-350lm 80*50 75 80 60
Grand

LED Downlight


Item Code Power Col.Temp PF Light Flux Dimension CRI Angle
OS-T15-3.5R 12 3000K >0.9 960-1080lm 92*65 80 60
OS-T15-3.5R 12 4000K >0.9 960-1080lm 92*65 80 60
OS-T15-3.5R 12 6500K >0.9 960-1080lm 92*65 80 60
Grand

LED Flash


Product Lumen Std. Packing
3w Flash 255 lm 20
6W Flash 540 lm 20
9W Flash 810 lm 20
12W Flash 1080 lm 20
Description Size Φ*H (mm) Cut out Size Φ(mm)
3W Flash 75*42 55mm
6W Flashh 95*47 75mm
9W Flash 117*55 95mm
12W Flash 140*55 125mm

* Available in 3 colors (White, Warm white, and Natural White)

* High Power Factor solution with 4Kv Surge & 440V High Voltage sustainability.

* Body Material-Polycarbonate

* Highly efficient optical lens
